Foldable FPV Drones——ZD Series
Built for the field: high speed, long endurance, 3-8 kg payloads, backpack-size foldable frame with second-level deployment.
Foldable FPV Drone Supplier
ZD Folding FPV Drone
Portable foldable aviation aluminum design
1200TVL, 165° distortion-free
0.001 LUX night vision camera
F405 V3 flight control millimeter-level attitude correction, high dynamic stability
Maximum speed reaches 160 km/h and Maximum load is 8 kg
Remote control up to 15 km
2.5W 5.8G Image Transmission + 915MHz receiver
Compatible with AI camera
Foldable FPV Drone ZD Series
| Item | ZD-10 | ZD-13 | ZD-15 |
| Specifications | 10 inches | 13 inches | 15 inches |
| Frame | Aerospace aluminum folding type | Aerospace aluminum folding type | Aerospace aluminum folding type |
| Motor | 3115-900KV | 4515-480KV | 4714-600KV |
| ESC | 60A 4-in-1 32-bits | 80A 4-in-1 | 100A 4-in-1 |
| Propeller | 10*5*3 Three-blade Prop | 13*5*3 Three-blade Prop | 13*5*3 Three-blade Prop |
| Flight Controller | F405 V3 | F405 V3 | F405 V3 |
| Image transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission |
| Camera | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX |
| Receiver | 915MHz Receiver | 915MHz receiver | 915MHz Receiver |
| Remote Controller | 1W Power 15km Range V14 | 1W Power 15km Range V14 | 1W Power 15km Range V14 |
| Battery | 6S 8000 65C | 8S 8000 65C | 8S 12000 |
| Load Capacity | Recommended 3000g Max 3500g | Recommended 5000g Max 6000g | Recommended 7000g Max 8000g |
| Flight Time | Empty 45mins 3000g 15 mins | Empty 40 mins 3000 g /20 mins 5000 g /14 mins | Empty 44 mins 3000 g /18 mins 4000 g /14 mins 8000 g / 7 mins |
| Wheelbase | 480mm | 520mm | 580mm |
| Dimensions | Expanded:345mm*335mm*142mm Folded:265mm*175mm*100mm | Expanded: 380mm*357mm*142mm Floded:265mm*175mm*100mm | Expanded:420mm*415mm*165mm Floded:265mm*185mm*100mm |
| Empty Weight | 2496g | 3147 grams | 6820 grams |
| Flight Speed | Empty 142km/h 3000g 120km/h | Empty 135 km /h 5000 g / 105km/h | Empty 160 km/h 3000 g / 132 km/h 8000 g / 91 km/h |
Foldable FPV Drone Price
Compatible with payload release
Foldable aviation aluminum fuselage
1. Aviation-grade materials: Aviation-grade aluminum alloy frame is durable and can be folded to save space.
2. When folded, the ZD-10 and ZD-13 measure only 265 × 175 × 100 mm.
3. The ZD-15 measures 265 × 185 × 100 mm when folded.
Flight speed and powerful load capacity
ZD-10: Unloaded speed of 142 km/h, flight time of 42 minutes; payload of 3 kg at a speed of 120 km/h, flight time of 15 minutes.
ZD-13: Unloaded speed of 135 km/h, flight time of 40 minutes; payload of 5 kg at a speed of 105 km/h, flight time of 14 minutes.
ZD-15: Unloaded speed of 160 km/h, capable of flying for 44 minutes; with an 8 kg payload, speed of 91 km/h, capable of flying for 7 minutes.
AI-compatible camera
AI camera available separately
Features a plug-and-play design (weight <200g/5-minute assembly), compatible with the three major flight control systems: Betaflight, ArduPilot, and CRSF. Enables seamless switching between manual and autonomous tracking modes through flight control-level integration. Operates stably in environments ranging from -20°C to 60°C, integrating visible light/infrared/thermal imaging multi-spectral sensing capabilities. It offers 1.2km human and vehicle recognition, 0.5s rapid locking, and 3-second obstacle reacquisition capability. Combined with PiP dual-stream transmission technology with <60ms latency, it ensures stable long-range tracking and real-time situational awareness performance.
Professional-grade aerial photography system
1. Low-light imaging: 1200TVL, 165° distortion-free, 0.001 LUX night vision.
2. Stable control: F405 V3 flight controller, millimeter-level attitude correction, high dynamic stability.
3. Long-range control: 15 km range; equipped with a 915 MHz receiver + 2.5W 5.8 GHz video transmission, enabling zero-latency high-definition signal transmission.
4. Engineering-grade load: Multiple installation positions and power supply reserves, pan-tilt/lighting/amplification/projection, etc.
Foldable FPV Drone
Critica-Area Protection
Perimeter patrol & anomaly detection, low-light capable.
Mobile Field Ops
Forward observation, route reconnaissance, rapid deployment.
Industrial Inspection
Rooftops/towers/pipelines/PV; optional AI defect detection.
Event Imaging Support
Security footage and low-latency feed; high-speed chase shots.
FAQ
The ZD-15 is engineered for extreme performance, boasting a $180\text{ km/h}$ top velocity and a massive $8\text{ kg}$ maximum payload. Unlike standard frames, this folding FPV drone balances speed with lifting power, making it the ideal choice for deploying heavy sensors or tactical equipment in rapid-response scenarios.
As a leading foldable fpv drone manufacturer, we utilize high-modulus 3K carbon fiber and reinforced aviation-grade aluminum joints. This proprietary design ensures that even during 44-minute extended flight times, the collapsible arms remain rigid and vibration-free, maintaining Level 7 wind resistance under full load.
Our premium foldable fpv drones are equipped with a 2000TVL high-definition night vision camera and a high-gain transmission system. This setup provides a reliable $15\text{ km}$ operational range, ensuring crystal-clear visual data and signal stability for 24/7 search, rescue, and security monitoring.
Yes. Seboar is a specialized foldable fpv drone supplier. We provide comprehensive bespoke OEM services for global partners, including custom motor KV ratings for specific altitudes, tailored frame dimensions, and localized frequency integration ($2.4\text{G}/915\text{MHz}$) to meet the needs of every foldable fpv drone distributor.
We offer tiered foldable fpv drone cost structures for our wholesale partners. To receive a detailed foldable fpv drone quote or a comprehensive foldable fpv drone datasheet, please contact our sales department. We provide factory-direct technical support and rapid component fulfillment for our global distributor network.
Foldable FPV Drone Frame ZD Series
| Product Specifications | 10 inches | 13 inches | 15 inches |
| Frame Type | Width X | Width X | Width X |
| Dimensions | Unfolded: 345mm x 335mm x 142mm Folded: 265mm x 175mm x 100mm | Unfolded: 380mm x 357mm x 142mm Folded: 265mm x 175mm x 100mm | Unfolded: 420mm x 415mm x 165mm Folded: 265mm x 185mm x 100mm |
| Wheelbase | 480mm | 520mm | 580mm |
| Weight | 490g | 540g | 630g |
| Frame Material | 6063 aerospace aluminum alloy (entire unit) | 6063 aerospace aluminum alloy (entire unit) | 6063 aerospace aluminum alloy (entire unit) |
| Top Plate | 1.5mm | 1.5mm | 1.5mm |
| Bottom Plate | 1.5mm | 1.5mm | 1.5mm |
| Side Plate | Plastic | Plastic | Plastic |
| Arm | 6mm | 8mm | 8mm |
| Flying Tower | 30.5 x 30.5 mm | 30.5 x 30.5 mm | 30.5 x 30.5 mm |
| Image Transmission | 20 x 20 — 30.5 x 30.5 mm | 20 x 20 — 30.5 x 30.5 mm | 20 x 20 — 30.5 x 30.5 mm |
| Motor | 19 mm | 19 mm | M3 x 16–19 mm |
| Camera | 19 mm | 19 mm | 19 mm |
| Internal Space Height | 26 mm | 26 mm | 26 mm |
Seboar News
Foldable FPV Workhorse Drones——ZD Series
Built for the field:
high speed, long endurance, 3-8 kg payloads,
backpack-size foldable frame with second-level deployment.
Foldable FPV
Workhorse Drones——ZD Series
ZD Folding FPV Drone
ZD Folding FPV Drone
Portable foldable aviation aluminum design
1200TVL,165°distortion-free
0.001 LUX night vision camera
F405 V3 flight control millimeter-level attitude correction, high dynamic stability
Maximum speed reaches160km/h and Maximum load is 8 kg
Remote control up to 15 km
2.5W 5.8G image transmission + 915MHz receiver
Compatible with AI camera
Foldable FPV Drone ZD Series
| Item | ZD-10 | ZD-13 | ZD-15 |
| Specifications | 10 inches | 13 inches | 15 inches |
| Frame | Aerospace aluminum folding type | Aerospace aluminum folding type | Aerospace aluminum folding type |
| Motor | 3115-900KV | 4515-480KV | 4714-600KV |
| ESC | 60A 4-in-1 32-bits | 80A 4-in-1 | 100A 4-in-1 |
| Propeller | 10*5*3 Three-blade Prop | 13*5*3 Three-blade Prop | 13*5*3 Three-blade Prop |
| Flight Controller | F405 V3 | F405 V3 | F405 V3 |
| Image transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission |
| Camera | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX |
| Receiver | 915MHz Receiver | 915MHz receiver | 915MHz Receiver |
| Remote Controller | 1W Power 15km Range V14 | 1W Power 15km Range V14 | 1W Power 15km Range V14 |
| Battery | 6S 8000 65C | 8S 8000 65C | 8S 12000 |
| Load Capacity | Recommended 3000g Max 3500g | Recommended 5000g Max 6000g | Recommended 7000g Max 8000g |
| Flight Time | Empty 45mins 3000g 15 mins | Empty 40 mins 3000 g /20 mins 5000 g /14 mins | Empty 44 mins 3000 g /18 mins 4000 g /14 mins 8000 g / 7 mins |
| Wheelbase | 480mm | 520mm | 580mm |
| Dimensions | Expanded:345mm*335mm*142mm Folded:265mm*175mm*100mm | Expanded: 380mm*357mm*142mm Floded:265mm*175mm*100mm | Expanded:420mm*415mm*165mm Floded:265mm*185mm*100mm |
| Empty Weight | 2496g | 3147 grams | 6820 grams |
| Flight Speed | Empty 142km/h 3000g 120km/h | Empty 135 km /h 5000 g / 105km/h | Empty 160 km/h 3000 g / 132 km/h 8000 g / 91 km/h |
Portable foldable aviation aluminum design
1200TVL, 165° distortion-free
0.001 LUX night vision camera
F405 V3 flight control millimeter-level attitude correction, high dynamic stability
Maximum speed reaches 160 km/h and Maximum load is 8 kg
Remote control up to 15 km
2.5W 5.8G image transmission + 915MHz receiver
Compatible with AI camera
Foldable FPV Drone ZD Series
| Item | ZD-10 | ZD-13 | ZD-15 |
| Specifications | 10 inches | 13 inches | 15 inches |
| Frame | Aerospace aluminum folding type | Aerospace aluminum folding type | Aerospace aluminum folding type |
| Motor | 3115-900KV | 4515-480KV | 4714-600KV |
| ESC | 60A 4-in-1 32-bits | 80A 4-in-1 | 100A 4-in-1 |
| Propeller | 10*5*3 Three-blade Prop | 13*5*3 Three-blade Prop | 13*5*3 Three-blade Prop |
| Flight Controller | F405 V3 | F405 V3 | F405 V3 |
| Image transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission | 2.5W 5.8GHz video transmission |
| Camera | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX | 1200TVL 165 degree wide angle 0.001LUX |
| Receiver | 915MHz Receiver | 915MHz receiver | 915MHz Receiver |
| Remote Controller | 1W Power 15km Range V14 | 1W Power 15km Range V14 | 1W Power 15km Range V14 |
| Battery | 6S 8000 65C | 8S 8000 65C | 8S 12000 |
| Load Capacity | Recommended 3000g Max 3500g | Recommended 5000g Max 6000g | Recommended 7000g Max 8000g |
| Flight Time | Empty 45mins 3000g 15 mins | Empty 40 mins 3000 g /20 mins 5000 g /14 mins | Empty 44 mins 3000 g /18 mins 4000 g /14 mins 8000 g / 7 mins |
| Wheelbase | 480mm | 520mm | 580mm |
| Dimensions | Expanded:345mm*335mm*142mm Folded:265mm*175mm*100mm | Expanded: 380mm*357mm*142mm Floded:265mm*175mm*100mm | Expanded:420mm*415mm*165mm Floded:265mm*185mm*100mm |
| Empty Weight | 2496g | 3147 grams | 6820 grams |
| Flight Speed | Empty 142km/h 3000g 120km/h | Empty 135 km /h 5000 g / 105km/h | Empty 160 km/h 3000 g / 132 km/h 8000 g / 91 km/h |
Foldable FPV Drone Price
Foldable FPV Drone Price
Foldable aviation aluminum fuselage
1. Aviation-grade materials: Aviation-grade aluminum alloy frame is durable and can be folded to save space.
2. When folded, the ZD-10 and ZD-13 measure only 265 × 175 × 100 mm.
3. The ZD-15 measures 265 × 185 × 100 mm when folded.
Flight speed and powerful load capacity
ZD-10: Unloaded speed of 142 km/h, flight time of 42 minutes; payload of 3 kg at a speed of 120 km/h, flight time of 15 minutes.
ZD-13: Unloaded speed of 135 km/h, flight time of 40 minutes; payload of 5 kg at a speed of 105 km/h, flight time of 14 minutes.
ZD-15: Unloaded speed of 160 km/h, capable of flying for 44 minutes; with an 8 kg payload, speed of 91 km/h, capable of flying for 7 minutes.
AI-compatible camera
AI camera available separately
Features a plug-and-play design (weight <200g/5-minute assembly), compatible with the three major flight control systems: Betaflight, ArduPilot, and CRSF. Enables seamless switching between manual and autonomous tracking modes through flight control-level integration. Operates stably in environments ranging from -20°C to 60°C, integrating visible light/infrared/thermal imaging multi-spectral sensing capabilities. It offers 1.2km human and vehicle recognition, 0.5s rapid locking, and 3-second obstacle reacquisition capability. Combined with PiP dual-stream transmission technology with <60ms latency, it ensures stable long-range tracking and real-time situational awareness performance.
Professional-grade aerial photography system
1. Low-light imaging: 1200TVL, 165° distortion-free, 0.001 LUX night vision.
2. Stable control: F405 V3 flight controller, millimeter-level attitude correction, high dynamic stability.
3. Long-range control: 15 km range; equipped with a 915 MHz receiver + 2.5W 5.8 GHz video transmission, enabling zero-latency high-definition signal transmission.
4. Engineering-grade load: Multiple installation positions and power supply reserves, pan-tilt/lighting/amplification/projection, etc.
Foldable aviation aluminum fuselage
1. Aviation-grade materials: Aviation-grade aluminum alloy frame is durable and can be folded to save space.
2. When folded, the ZD-10 and ZD-13 measure only 265 × 175 × 100 mm.
3. The ZD-15 measures 265 × 185 × 100 mm when folded.
Flexible take-off and landing,
strong environmental adaptability
The vtol uav fixed wing combines vertical takeoff and landing (VTOL) with efficient fixed-wing flight, making it suitable for operations in challenging terrain. Its hybrid design ensures reliable performance in varied environments.
Long endurance
to meet operational needs
AI camera available separately
The vtol fixed wing uav offers approximately 20 minutes of hover time and up to 60 minutes of cruise flight, providing sufficient endurance for extended operations over larger areas. This balanced performance makes it practical for field applications requiring sustained airtime.
Professional flight control system,
stable and reliable
The vtol uav fixed wing is equipped with a professional-grade Ardupilot open-source flight control system, which provides GPS positioning capability of up to ±1 meter accuracy with stable and reliable performance, and supports SBUS/CRSF remote control communication protocols, combining algorithmic maturity and operational flexibility.
Foldable FPV Drone Frame ZD Series
| Product Specifications | 10 inches | 13 inches | 15 inches |
| Frame Type | Width X | Width X | Width X |
| Dimensions | Unfolded: 345mm x 335mm x 142mm Folded: 265mm x 175mm x 100mm | Unfolded: 380mm x 357mm x 142mm Folded: 265mm x 175mm x 100mm | Unfolded: 420mm x 415mm x 165mm Folded: 265mm x 185mm x 100mm |
| Wheelbase | 480mm | 520mm | 580mm |
| Weight | 490g | 540g | 630g |
| Frame Material | 6063 aerospace aluminum alloy (entire unit) | 6063 aerospace aluminum alloy (entire unit) | 6063 aerospace aluminum alloy (entire unit) |
| Top Plate | 1.5mm | 1.5mm | 1.5mm |
| Bottom Plate | 1.5mm | 1.5mm | 1.5mm |
| Side Plate | Plastic | Plastic | Plastic |
| Arm | 6mm | 8mm | 8mm |
| Flying Tower | 30.5 x 30.5 mm | 30.5 x 30.5 mm | 30.5 x 30.5 mm |
| Image Transmission | 20 x 20 — 30.5 x 30.5 mm | 20 x 20 — 30.5 x 30.5 mm | 20 x 20 — 30.5 x 30.5 mm |
| Motor | 19 mm | 19 mm | M3 x 16–19 mm |
| Camera | 19 mm | 19 mm | 19 mm |
| Internal Space Height | 26 mm | 26 mm | 26 mm |
Foldable FPV Drone
Foldable FPV Drone
Critica-Area Protection
perimeter patrol & anomaly detection, low-light capable.
Mobile Field Ops
forward observation, route reconnaissance, rapid deployment.
Industrial Inspection
rooftops/towers/pipelines/PV; optional AI defect detection.
Event Imaging Support
security footage and low-latency feed; high-speed chase shots.
Interested in becoming a reseller or placing a high-volume order? Contact us for exclusive bulk pricing and save big!
